Capabilities

CNC MILLING

Envelope up to X-45”, Y-25” and Z-24”, 10,000 RPM spindle. Custom fixtures built in-house.

CNC BENDING

Up to 250 ton, 168″ (14′) 8 axes CNC back gauging. Cadman 3-D programming.

MEMBER

GREEN MOUNTAIN GRILLS DEALER

CNC TURNING

Turning centers with sub-spindles. Work envelope of X-10.200”, Z-23.2” and B-24.6”. 6000 RPM spindle. 6’ servo-driven auto Bar feeder.

CNC PLASMA CUTTING

Hypertherm Edge PRO with HPR130XD-High Performance Plasma System. Hypertherm Edge PRO with HPR260XD-High Performance Plasma System.
Maximum cutting capacity is 2-1/2” mild steel, 3/4″ stainless steel and 5/8″ aluminum
True hole technology. Gantry table 9’ x 12’ cutting size. Gantry table 8′ x 20′ cutting size.

CNC SAW CUTTING

12” x 12” fully automatic bundle cutting. High Precision cutting capabilities. 30 deg miter cutting.

MIG WELDING

Certified welders (AWS D1.1 and D15.1 Certified) Steel, aluminum and stainless steel. Welding turntables.

POWDER COATING

Powder Coating batch system with oven size of 10′ x 10′ x 20′.

LOGISTICS

Delivery Shipping

OTHER CAPABILITIES

Punching. Iron Worker. Assembly. Manual Brake Press.
